The Battery Fuse 250A NH1 HRC 500V is an NH fuse link for overload and short-circuit protection. It fits NH1 holders and protects high-current battery and inverter cables up to 250A.
Developers, solar installers, factories and farms use it across South Africa on large battery banks. Browse more fuse links and bases in our Fuse and Holder range.
Battery Fuse 250A NH1 HRC 500V Benefits
- Handles 250A on high-current battery and inverter cables.
- Knife blade contacts plug straight into an NH1 holder.
- Made to IEC/EN 60269-1 and IEC/EN 60269-2 fuse standards.
Key Specifications And Ratings
- Brand: DF Electric
- Model: NH1
- Breaking Capacity: 120kA
- Frequency: 42–62Hz
- Standards: IEC/EN 60269-1, IEC/EN 60269-2
- Certifications/Markings: CE, UKCA, EAC
- Product Code: 381270
- Fuse Type: NH HRC Knife Blade Fuse
- Rated Current: 250A
- Rated Voltage: 500V AC
- Fuse Classification: gG/gL
- Protection: Overload and Short Circuit
- Power Dissipation: 20.2W
- Mounting: NH1 Fuse Holder
- Weight: 380g
- Dimensions: 135 × 68 × 62mm
gG/gL means full-range protection, from slow overloads to heavy short circuits. Its 120kA breaking capacity clears very high fault currents.
Weighing 380g, the fuse measures 135 × 68 × 62mm and dissipates 20.2W. It’s made in Spain and rated for 42-62Hz AC supplies.
Compatibility And NH1 Holder Fit
This electric fuse only fits NH1 holders and NH1 fuse bases, so match the holder first. NH00, NH2 and NH3 holders take different sizes and will not accept it. Check the size listed on our fuse holder product page before you order.
The rated voltage is 500V AC, and the product page lists no DC rating. Without a suitable DC rating, the fuse may not clear a battery fault safely. Ask us to confirm the DC rating before you fit it to a battery bank.
Once confirmed, it can act as an inverter fuse on 250A supply cables. Choose cables rated for 250A from our battery cable range. Smaller systems may suit our 160A battery protection fuse instead.
Large battery banks often use our 5 hole battery busbar box to join cables. Browse more parts in our battery and inverter accessories range. Find more protection gear in our Switchgear & Protection range.
Best Use Cases For Battery Banks
- Installers replacing a blown HRC fuse after a fault.
- Factories and businesses running high-current inverter systems.
- Farms and off-grid properties with large battery banks.
Warranty Compliance And Trust
Read the general rules for fuse links in the IEC 60269-1 low-voltage fuse standard. CE, UKCA and EAC markings appear on the fuse, but they are not South African approvals.
Fitting must follow SANS 10142-1, the South African wiring code for low-voltage installations. A registered electrical contractor must fit it and issue a Certificate of Compliance under the Electrical Installation Regulations.
Our solar installation team handles this work across the Vaal Triangle and Gauteng. Installations include a 12-month workmanship warranty, confirmed with your quote. No separate product warranty is listed for this fuse.
Solar Panel Energy has 13 years of experience and 500+ completed projects. Pay by EFT, card, cash or PayFast. Stock sits in 7 warehouses, with nationwide delivery in 2 to 5 working days.
Read our solar equipment FAQs for answers on ordering and delivery. Types of fuses differ in size and rating, so ask us if you’re unsure.
Contact our sales team to order the Battery Fuse 250A NH1 HRC 500V with nationwide delivery. Call +27 81 841 7188 to check the DC rating of any battery fuse for inverter cables.
